Automotive Oscilloscope USB 8 Channels PC Based Storage Digital Multimeter Osciloscopio Logic Analyzer Diagnostic-tool. Cost-effective Hantek PC USB 8CH Automotive Diagnostic Oscilloscope/DAQ/Programmable Generator: Highly efficient and cost -effective. 8 channels oscilloscope for vehicle testing. 2.4MSa/s real time sampling rate, 12bit vertical resolution.

10mV/div to 5V/div input sensitivity. 8 channels programmable generator which can analog signals of crankshaft, camshaft, etc. First Diagnosis: Intake manifold vacuum & ignition, Petrol fumes adjusting valve vacuum & ignition, Idle exhaust ignition, Starting exhaust ignition. Sensor: Air Flow Meter, Camshaft, Crankshaft, Distributor, Lambda sensor, Throttle position.

Bus Diagnosis: CAN bus data examine, CAN bus signal integrity, CAN bus LH long time acquisition, LIN bus. 8 channels oscilloscope, 2.4MSa/s real time sampling rate.

12 bits vertical resolution, spectrum analysis function. Can analog signals of crankshaft, camshaft etc.

USB 2.0 interface plug and play, and no need extra power supply. More than 20 types of automatic testing function, a similar interface with benchtop oscilloscope, easy to use. Software support: Windows NT, Window 2000, Windows XP, VISTA, Windows 7, Window 8, Window 10.

CH1, CH2, CH3, CH4, CH5, CH6, CH7, CH8. Vpp, Vamp, Vmax, Vmin, Vtop, Vmid, Vbase, Vavg, Vrms, Vcrms, Preshoot, Overshoot. Frequency, Period, Rise Time, Fall Time, Positive Width, Negative Width, Duty Cycle.

Horizontal , Vertical, Track, Auto Measure Modes. +, - , x, ÷, FFT, Invert. Rectangular, Hanning, Hamming, Blackman Window. 1 x 1008C DAQ oscilloscope. 1 x CD driver etc. There are three functions of vehicle diagnosis, oscilloscope and signal generator, including 78 types of vehicle diagnosis function. Save the current waveform and generate pictures. Storage location is optional and easy to find.

Standard reference waveform inside and can be callout or close with one button. It is convenient to be compared.

20 types of automatic measurement method which can be callout or close with one button. It is convenient and visual to read out the result.

The result can be printed with one button and generate diagnosis report which is easy to be saved and recorded. The user can save the waveform as REF format and callout it again when you need to compare the two waveforms catched in different time. The diagnosis result can be saved as the format of txt, csv, rfc, xls, doc, jpg and etc. It is convenient to be checked and compared later. 8CH signal can be measured simultaneously. The measurement voltage of each channel can be adjusted independently.

You can choose to open or close each channel. Support to record and replay the waveform. The waveform can be save into the computer hard disk and easy to read. There is no limit to the record time which can long-time measure and record the waveform for troubleshooting.

Support the display surface in Chinese, English, German language, and it can be switched freely. Support 4 types of cursor measurement mode -cross, track, horizontal, and vertical. It's easy to read out the time and voltage of irregular signal. The background color is optional as user's preference.

And the lightness of waveform and gridding is settable. USB2.0 power supply + communication interface, plug and play, and support hot plugging. Signal generator function, can simulate crankshaft and camshaft signal. It usually takes around 3 to 4 weeks to United Stated, United Kingdom, Australia, Canada and some European countries.

But for other countries, it may need 5-7 weeks to deliver the parcel. All items will be tested or checked carefully and packaged in good condition before sending out to you. Some faulty items might happen especially after overseas transportation. We promise we will provide prompt and satisfactory solution to you. Your 100 satisfaction is our greatest goal here.
